AVZ-2320
Avza Tech Box PCs are designed for high stability and suitable for a wide range of temperatures.
Specifications
| Specifications | |||
| System | Enviroment | ||
| CPU | Intel 4th Core i3/i5 CPU Onboard | Operating temperature(°C) | 0~50 °C |
| System Memory | Onboard 4GB DDR3L 1600MHz SDRAM | Storage temperature(°C) | -30~70 °C |
| Power Consumption | Max:44.2W@12V | Storage humidity | Storage humidity 10%~90%@ 40°C, non-condensing |
| Certification | CE / FCC Class A | ||
| USB | 2 x USB 3.0 type A, 4 x USB 2.0 type A | Operating System Support | |
| Serial / Parallel | 3 x RS-232 DB-9 | Operating System Suppor | Windows 7 Pro for Embedded, Windows Embedded Standard 7, Windows Embedded 8.1 Industry Pro, Windows Embedded 8 Standard, Windows 10 IOT 2016 |
| Audio | 1 x Line-out | ||
| Graph | 1 x VGA, 1 x HDMI | ||
| LAN | 2 x GbE LAN RJ-45 | ||
| Power | 1 x 3-pin DC power input terminal, 1 x power button | ||
| Storage Space | |||
| HDD | 1 x 2.5" SATA3 HDD bay (easy accessible) | ||
| Expansion | |||
| Expansion slot | 1 x Mini-PCIe Slot Full Size | ||
| Power | |||
| Power input | 9~36V DC | ||
| Mechanical | |||
| Construction | Plating Titanium Gray Aluminum Heatsink and Black Steel Chassis | ||
| IP rating | IP20 | ||
| Mounting | Wall Mount | ||
| Dimension(mm) | 247 x 149 x 68 | ||
| Net weight(Kgs) | 2.5 | ||
>
>
>
